Reading an NMRDA layout sheet before you book a plot
Road widths, amenity reservations, setback lines, and DP reservations—decoded for buyers comparing Wardha Road to peripheral townships.
Locate the orientation block: true north versus marketing render north often diverge once you transpose Google Earth contours. Double-width roads usually signal collector roads; internal 9 m roads feel adequate today but constrain guest parking tomorrow. Amenity plots reserved for playgrounds or garden uses must retain their earmarking till handover—you can cross-check adjoining survey numbers during title diligence. Drainage flow arrows show low pockets; insist on podium or plinth clarification for corner plots bordering nullahs.
Match physical site to sheet
Carry laminated layout extracts on site walks. Pace out frontage multiples (allow tape tolerance) against abutting ROW before locking a preference lot. If widening buffers show “proposed DP road”, ask municipal gazette timelines—silent assumptions create holding costs when families build early.
